Technical Parameters Main Feature
1.Android System:carrying 32/64 bit high performance CPU and large capacity memory.
2.Support for multitask running at the same time:Support multi task operation,support for parallel implementation software,meet the application requirements of personalized business.
3.Flexible configuration:providing a variety of flexible communication mode selection,ensuring communication speed and security of transactions.
4.High security:providing multiple security protection,ensure the security of sensitive data.
5.High speed printing:set-in high-speed thermal printer,easy to load paper.
Items | Specifications | |
| Model | HGT-55 | HGT-55 LTE |
CPU | 4x Cortex-A7 1.3GHz | 4x Cortex-A53 1.5GHz / 8x Cortex-A53 1.7GHz |
| Financial Module：ARM Cortex-M3TM @ 108 MHz | ||
| GPU | ARM Mali-400MP2 533MHz | ARM Mali-T720 MP2 450MHz~600MHz |
Operating System | Android4.4.2 | Android 6.0 |
Memorizer | 4GB ROM+512M RAM | 1GB/2GB/3GB ROM + 8GB/16GB/32GB eMMC |
| Financial Module:1MB Program Flash，8/16MB Data Flash | ||
Communication | 2G：GSM/GPRS ( 850 / 900 / 1800 / 1900 ) MHz | 2G：GSM/GPRS ( 850 / 900 / 1800 / 1900 ) MHz |
| 3G：WCDMA （850 or 900 / 1900 / 2100 ）MHz | 3G：TDS（34/39 ）, WCDMA（B1/B2/B5/B8 ）,CDMA2000（BC0） | |
| / | 4G：TDD（38/39/40/41 ）, FDD（1/2/3/4/5/7/8/17/20/12/13/28） | |
| BT4.0LE+ EDR | BT4.0LE | |
| WIFI IEEE802.11 b/g/n | Support hot spots（5G 802.11.AC） | |
| GPS，support for A-GPS | GPS，support for A-GPS BDS（option） | |
| Screen | 3.5' TFT LCD+TP , 320*480 Dot matrix STN LCD 96*16 customer display | |
| OLED 128*64 Lattice | ||
Keyboard | 10 Numeric keys,11 Function keys | |
Magnetic Card Reader | 3 rail tracks,support bidirectional card,according with ISO7810、7811 standard | |
IC Card Reader | 1 pc,according with EMV/PBOC Standard | |
SAM Card Reader | 2 pcs,according with ISO7816 standard | |
Contactless IC Card Reader | 1 pc , support for ISO14443 Type A/B,Mifare 1 card | 1 pc , support for ISO14443 Type A/B,Mifare DESFire card |
| Support ISO15693 RFID（option） | ||
| Fingerprinter(option) | 508 DPI resolution；112*96 pixel sensor array False Accept Rate （FAR）：< 0.0005%；False Rejection Rate （FRR）：< 1% | |
Tax Inspection Module(option) |
| |
Printer | 58mm high speed thermal printer,the maximum diameter of paper roll is 30mm | |
Physical Interface | TF card slot*1/Micro USB*1/External Power IN*1/SIM card slot*1/PSAM card slot*2 | |
Power Adapter | DC 5V 4A | |
Battery | 3.7V 6000mAh lithium-ion battery | |
Outline Dimension | 220mm×75mm×55mm（L×W×H） | |
Weight | 470g(Without battery) | |
Environmental Requirements | Working temperature:-10℃～+45℃； | |
Bar Code Reader | 1D/2D(option) | |
Camera | 5.0M AF | |
Foundation Certificate | Contact EMV 4.3/PBOC 3.0 L1 Contactless EMV 2.3/QPBOC L1 CE、CCC China UnionPay PIN input equipment security certification | |
Additional Application Certificate | Contactless Master PayPass / VISA PayWave / QPBOC China UnionPay accepting terminal product authentication | |
(The information shown here is indicative only,If there is inconsistency between the specification and the actual product,the actual product shall govern.) | ||
